0.6/1 kV NYBY Cable(CU/PVC/STA/PVC)

0.6/1 kV NAYY Cable(AL/PVC/PVC)

  • 1 Core
  • 2 Core
  • 3 Core
  • 4 Core
  • 5 Core
  • 3+1 Core
  • 4+1 Core
  • 3+2 Core
    • Back
    Inquiry
    0.6/1kV-3+1 Core Copper Conductor PVC Insulated Steel Tape Armored PVC Sheathed Power Cable
    Nominal cross sectional area Insulation thickness Non-magnetic steel tape thickness Sheath thickness Approximate outer diameter Approx.
    weight     		Max.D.C resistance of conductor（20℃） Current carrying capacity
    mm2 mm mm mm mm kg/km Ω/km In Air(A) In Ground(A)
    3*4+1*2.5 1.0/0.8 0.2 1.8 16.7 667 4.61/7.41 - -
    3*6+1*4 1.0/1.0 0.2 1.8 18.2 581 3.08/4.61 - -
    3*10+1*6 1.0/1.0 0.2 1.8 20.8 787 1.83/3.08 50 70
    3*16+1*10 1.0/1.0 0.2 1.8 23.5 1074 1.15/1.83 66 92
    3*25+1*16 1.2/1.0 0.2 1.8 27.2 1497 0.727/1.15 85 115
    3*35+1*16 1.2/1.0 0.2 1.8 28.4 1795 0.524/1.15 105 140
    3*50+1*25 1.4/1.2 0.2 2.0 32.8 2396 0.387/0.727 125 175
    3*70+1*35 1.4/1.2 0.5 2.1 38.0 3584 0.268/0.524 160 205
    3*95+1*50 1.6/1.4 0.5 2.3 43.0 4669 0.193/0.387 195 250
    3*120+1*70 1.6/1.4 0.5 2.4 47.3 5825 0.153/0.268 235 290
    3*150+1*70 1.8/1.4 0.5 2.5 51.0 6804 0.124/0.268 265 325
    3*185+1*95 2.0/1.6 0.5 2.7 56.2 8430 0.0991/0.193 300 365
    3*240+1*120 2.2/1.6 0.5 2.9 62.7 10701 0.0754/0.153 355 420
    3*300+1*150 2.4/1.8 0.5 3.1 68.9 13115 0.0601/0.124 410 475
